General Description
Operating mass: 11400 kg
Max. Operating mass: 12800 kg
Module mass (front/rear): 6800 kg/ 4600 kg
Speed range (Dual/TC/AS): 0 – 8 km/h
Max. theoretical gradeability: 49 %
Drum Width: 2130mm
Static linear load: 32 kg/cm
Nominal amplitude (high/low): 1.8mm/0.9 mm
Vibration frequency (high/low amplitude): 33 Hz
Centrifugal force (high/low amplitude): 250 kN/130 kN
Fuel tank capacity: 280L
Hydraulic system
Integrated Active Bouncing Control
