General Description
SCHWING portable concrete pumps are successfully deployed worldwide wherever vast quantities of concrete have to be pumped over exceptionally long horizontal and vertical distances. In building and civil engineering projects, they are also fast, reliable and economically efficient in handling pumpable concretes under extreme conditions with regard to concrete designs, job sites and climate.
- Designed to meet long horizontal and vertical pumping demands.
- Rugged reliable rock valve for tough site conditions as in India.
- Compact design FAST switching valve for quick operation of Rock valve.
- Theoretical pumping of 64cbm/hr. or Maximum concrete pressure of 142 bar
TECHNICAL SPECIFICATION
Version: Diesel *
Motor / Engine Rating: 75kw
Nominal Speed: 2300rpm
Pumping cylinder Dia X Stroke: 200*1400mm
Differential cylinder Drive: PS/RS
Max. Stroke count per min: 16/27
Max. Theoretical output: 42/72cbm/hr.
Max. concrete pressure: 112/62bar
